Yamaha AG03 AG Series Mixer Console Multipurpose 3-Channel Mixer with USB Audio Interface

Description

Yamaha AG03 AG Series Mixer Console Multipurpose 3-Channel Mixer with USB Audio Interface

---

Yamaha AG Series AG03 Mixer Console Multipurpose 3-Channel Mixer With USB Audio Interface is perfectly designed to transform your Mac, PC, or even your iPad into a virtual radio station and spread your information to the world. Including an incredibly simple setup process, the AG lets you create online content with high-resolution sound, both for real-time broadcast over digital streaming platforms such as YOUTUBE LIVE or USTREAM, or producing on-demand videos and podcasts. Yamaha AG will upgrade your production cost considerably with sound effects, background music, and a level of sound quality that can’t be met with a standard headset/computer configuration.

---

LOOPBACK function for internet live streaming

LOOPBACK function allows live broadcasting of all the instruments, microphones, and other background music with audio sources along from your PC / Mac or iPad.

---

D-PRE professional-quality mic preamp

AG03 is equipped with the same premium mic preamps developed by Yamaha for professional recording consoles, capturing the most specific nuances of your instrumental or vocal performance.

---

Flexible connectivity

Yamaha AG03 arrives outfitted with an input featuring dynamic power as well as a headset input, providing you the opportunity to use a professional conventional computer headset or condenser mic.

---

Control

This Mixer Console model comes with volume knobs and a 60mm fader on the front panel for easy manual control of your background music and voice, and other sound effects or audio content.

---

1-TOUCH DSP provides professional sound with a single touch

1-TOUCH COMP/EQ can add accuracy and focus to your sound with the easy click of a key. Exactly like a genuine radio broadcast, you can add reverb with the 1-TOUCH EFFECT or sound effects from an outside device at will.

---

High-quality Compliant mode for iPad connection

The AG03 is cooperative with Apple’s second-generation iPad or other, providing you to produce a professional-quality recording and playback utilizing an iOS fit music app such as Cubasis.

---

Cubasis LE Multitouch Sequencer for the iPad

Cubasis LE is available in the App Store. Now connect your AG03 with your iPad to make it work. Cubasis LE is the portable version of Steinberg’s streamlined, multitouch sequencer for the iPad, giving the identical feel and look like its greater brother Cubasis. Uniquely designed for fast and simple operation, Cubasis LE offers editing, recording, and Mixer a breeze. Touch-intuitive Cubasis LE production tools in your hands, starting a new world of opportunities for your creativity.

---

Strong, compact metal chassis

The sturdy metal body of the AG is very easy and portable to place on a guitar case, on a keyboard, or also on a mic stand using an optional adapter.

---

AG DSP Controller provides added control of DSP settings

In addition, multi-platform AG DSP Controller software app, you can edit the compressor, and access EQ, high-pass filter, reverb, and amp simulator parameters of your 1-TOUCH DSP. EASY style provides you well-defined, intuitive control, while EXPERT mode lets you more precise adjustment of your parameters.

---

Cubase AI Music Production Software

Cubase AI Digital Audio Workstation (DAW) software comes with your AG purchase providing you a streamlined but sturdy music production tool for creating professional-quality recordings right out of the box.

---

High resolution (192 / 24bit) recording and playback

Yamaha AG03's professional-quality design allows 192kHz / 24bit sound that can reproduce yet the most detailed nuances of your original recordings. In 192kHz/24bit sound quality is perfect for capturing the most transparent reproduction of your analog recordings when archiving your valued collection.

---

USB bus-powered or mobile battery

The durable and compact AG can be performed using a mobile battery or USB bus power, providing you a powerful mobile setup that can match easily into a backpack.

---

Product Features:

• High-quality multipurpose 3-channel mixer with USB audio interface.
• Flexible LOOPBACK feature ideal for webcasting or live recording.
• High resolution (24-bit192kHz) 2-track audio playback and recording.
• D-PRE professional-quality mic preamps with low noise and high gain.
• +48V phantom power on CH1 input for Dl boxes and condenser mics.
• Hi-Z input for guitars on CH2.
• Simple control and pro sound with 1-TOUCH COMP/EQ, EFFECT processing.
• iPad (2 or later) connectivity via Apple iPad Camera Connection Kit (requires external USB power supply).
• USB bus-powered for PC and Mac.
• Sturdy metal chassis.
• Comes with Cubase Al downloadable version.

  ---

Product Details:

• Brand: Steinberg
• Model Number: AG03
• Series: AG
• Outline
• I/O: Phantom power: + 48 V
• Input Channels: Mono[MIC/LINE]: 1 including HEADSET MIC (Plug-in Power)
• Stereo[LINE]: 1 including Guitar input (Mono)
• AUX: 1
• Output Channels
• MONITOR OUT; 2
• PHONES: 2 including HEADSET PHONES
• Bus: Stereo: 1
• Input Channel Function
• PAD: 26 dB
• PEAK LED: LED turns on when the signal reaches 3 dB below clipping level
• On-board processors: CH1: COMP / EQ, EFFECT (SPX Reverb)
• Level Meter: USB Output Level; 2 x 2 point LED meter [PEAK, SIG]
• USB: USB Audio: 2 IN / 2 OUT, USB Audio Class 2.0 compliant, Sampling Frequency: Max 192 kHz, Bit Depth: 24-bit
• General specifications
• Power requirements: DC 5 V, 500 mA
• Power consumption: Max. 2.5 W
• System Requirements
• OS: Windows 7 or later / Mac OS X 10.7 or later
• Dimensions: 129 x 63 x 202 mm
• Weight: 0.8 kg
• Options: Foot Switch: FC5, Mic Stand Adaptor: BMS-10A
• Others: Foot Switch: EFFECT Mute on / off, Operating Temperature: 0 to + 40 °C
•  Manufacturer Warranty: 1 Year

• Country of origin: China
• Manufacturer details: YAMAHA
• Packer details: YAMAHA
• Importer details: YAMAHA
