Studiomaster Amplifier DPA 3200

Description

Studiomaster Amplifier DPA 3200:

The Studiomaster DPA 3200 power amplifier describes state-of-the-art professional character and appearance at an affordable price. It is absolutely suited for a broad range of sound reinforcement purposes including Professional touring, performing musicians and mobile entertainers. It has a Balanced/unbalanced inputs signal through parallel XLR connector in both channels.

Product Specifications:

• Two changeable speed fans.
• Expert high-power amplifiers.
• Low THD and high damping factor for the great sound character.
• Fast recovery plan for a lower twist if clipping occurs.
• Selectable sensitivity slide switch for ( 0.775V , 1V or 1.4V).
• Selectable slide switch for ground lift, Low cut and HF Limiter.
• Signal and Clip LED indicators to control performance.
• Front mounted detent gain commands for secure access.
• Indicators: Power On, Signal, Limiter, protect, Bridge.
• Cooling: Twin tunnel cooling fan with front - back air flow.
• Selectable slide switch for stereo, parallel and bridge mono amp modes.

Product Information:

• Brand: Studiomaster
• Model Number: DPA 3200
• Damping factor (8 Ω): > 300 :1
• Frequency Response: 20Hz - 20kHz (±0.5dB)
• Input Connector (Per CH.): XLR
• Output Connector (Per CH.): Speakon & Binding post
• Dimensions (WxDxH)mm: 483 x 455 x 130 (3U)
• Net Weight (Kgs.): 40.3
• Power output 2 Ω (RMS),20Hz-20kHz,1%THD: 2 x 1600 W
• Power output 2 Ω (EIA), 1kHz , 1%THD: 2 x 3900 W
• Power output 4 Ω (RMS),20Hz-20kHz,1% THD: 2 x 1200 W
• Power output 4 Ω (EIA), 1kHz , 1%THD: 2 x 2450 W
• Power output 8 Ω (RMS),20Hz-20kHz,1% THD: 2 x 800 W
• Power output 8 Ω (EIA), 1kHz , 1%THD: 2 x 1225 W
• Bridged Mode 4 Ω (RMS),20Hz-20kHz,1% THD: 3200 W
• Bridged Mode 4 Ω (EIA), 1kHz , 1%THD: 7800 W
• Bridged Mode 8 Ω (RMS),20Hz-20kHz,1% THD: 2400 W
• Bridged Mode 8 Ω (EIA), 1kHz , 1%THD: 4550 W
• Protection Devices: DC, Short Circuit, Over heat, Soft-Start, Clip Limit, Over load

• Country of origin: China
• Manufacturer details: STUDIOMASTER
• Packer details: STUDIOMASTER
• Importer details: STUDIOMASTER
