Zoom F4 Multitrack Field Recorder

Description

Zoom F4 Multitrack Field Recorder

Zoom F4 Multitrack Field Recorder is perfect for serious sound designers and filmmakers. 4 super moderate noise preamps record at up to 24-bit/192kHz resolution to present you the highest-quality audio for any project, with accuracy audio or video synching by using Temperature Compensated Crystal Oscillator (TCXO) clocking. A great LCD and dynamic gain knobs and PFL/Solo switches for a specific channel makes the F4 simple to operate in any situation. The full compact assembly also possesses BNC Time Code I/O and much more. You will be ready to capture world-class audio with Zoom's powerful F4 Multitrack Field Recorder.

You will get 4 locking Neutrik XLR/TRS combo jacks, particular with 6-segment LED level meter, gain control and PFL/Solo button. These inputs allow you to connect anything from phantom-powered condenser microphones to line-level origins. Cooler yet is the F4's modular development port, which allows you connect any of Zoom's acclaimed mic capsules. Its functionality and I/O offers you a wide range of field recording applications. Authorize dual-channel recording style on the Zoom F4 to perform safety tracks for inputs 1 and 2. These protection tracks can have their perspectives for level, delay, limiting, highpass filtering, phase inversion.

If you want to hear your audio in the field, you'll enjoy the supreme and flexible monitor section of the Zoom F4 Multitrack Field Recorder. It's vital to check your levels on the fly when you're sampling audio or filming. You can simply monitor single tracks or many tracks via easy-to-use front-panel keys and a comfortable 1/4 inch headphone output. Menu controls permit you to track audio to your right or left headphone channel, post or pre-fader, or even mono. The robust 100mW headphone amp has sufficient volume for even the loudest situations. There is more a collection of XLR outputs for transmitting audio to your studio monitors. This Recorder will encourage you to make the most of your recording time with its complete monitoring solutions.

Product Features:

• Microphone preamps with phantom power (+24/+48V) accommodate most analog connections and 4 XLR/TRS combination inputs.
• PFL buttons and Gain knobs for each input make setting levels quick and easy.
• Line-level outputs and headphones provide stereo sound for monitoring and playback.
• Fit with all of Zoom's mic capsules.
• Comprehensive LCD display makes navigation and setup extremely easy.
• Runs on either 12-volt adapter, 8 AA batteries, or DC battery packs via 4-pin Hirose connector.
• Includes a 12-volt power adapter, camera mount adapter, DHC-1 DC-HIROSE cable, and Cubase LE/WaveLab LE download codes.

Product Details:

• Brand: Zoom
• Model Number: F4
• Audio Interface: Yes
• A/D Resolution: Up to 24-bit/192kHz
• Simultaneous Rec Tracks: 6
• Simultaneous Play Tracks: 4
• Analog Inputs: 1 x 1/8 inch (line in/camera return), 4 x XLR-1/4 inch combo,10-pin Zoom capsule input
• Analog Outputs: 2 x XLR, 1 x 1/8 inch (sub out)
• Headphones: 1 x 1/4 inch
• Memory (removable): 2 x SD card slots (SD, SDHC, SDXC)
• USB: 1 x Type Mini-B
• Power Supply: 8 x AA batteries / External DC battery pack / 12V AC adapter with Hirose cable
• Battery Life: 8 trk 24/192kHz (2 hours Alkaline, 3.5 hours NiMH, 6 hours Lithium), 2 trk @ 16/48kHz (9.5 hours Alkaline, 17.5 hours Lithium)
• Stand Mountable:Built-in tripod mount
• Height: 2.1 inch
• Width: 7.0 inch
• Depth: 5.5 inch
• Weight: 1.02 kg

• Country of origin: China
• Manufacturer details: ZOOM
• Packer details: ZOOM
• Importer details: ZOOM
